Hole Hammer Positive Turn Reverse

Request a Quote

About this product

Contractors have counted on Vermeer for piercing tools since the very beginning of the trenchless age. Today, each positive turn reverse Hole Hammer puts the power of a proven, simple and reliable design in your hands—with legendary support and service from the industry’s largest distribution network. Vermeer Hole Hammers can handle a full range of projects, including gas and electric, fiber and telecom, water and irrigation installations.

Product Videos

Key Features

EASY TO SERVICE

An innovative tailbolt design that provides excellent rear anvil clamping force yet only requires 35 ft lbs of torque to gain access to the tool assembly. This design can be quickly and easily field serviced in minutes with basic hand tools.

REPLACEABLE HEAD DESIGN

Replaceable head design is heat-treated alloy to protect the tool body and can be replaced to extend the tool body life cycle.

PERFORMANCE

Runs one of the heaviest striker to body weight ratios on the industry for maximum power and performance.

Hole Hammer Positive turn piercing tool
positive turn

SUPERIOR RELIABILITY

This 22 year design has proved itself over the test of time to be the most reliable, low cost designs in the industry with only 18 parts in the tool assembly.

OILER ASSEMBLIES

Oiler assemblies come standard with Quick Reverse Swivel kit for air-on reversing; and feature a sight glass to see oil level and a pressure relief cap.

Positive Turn Reverse

FREE FLOATING VALVE

A simple compression fitting design that is able to self-center in the tool striker for easy starts and no tool binding.

KEEPS YOU ON THE JOB LONGER

Field Serviceable external hose design allows the ability to change quickly without tool disassembly.

Available Accessories

Available Options

Hole Hammer Quarter Turn

Vermeer Hole Hammers can handle a full range of Trenchless installation projects including gas, cable, electric, water and irrigation systems.

Moving Head Tools

The moving head design provides the power to get the job done in the toughest of conditions. It allows 100% of the energy to be transferred through the head which increases production and accuracy in compact soil conditions.
Short Tools

Short Tools

Short tools allow customers minimal surface disruptions while maintaining productivity in confined suburban areas.

Literature

Literature

Package

Specifications

VPT 200
  • Diameter – 2″
  • Length – 45.3″
  • Weight – 28 lb
  • Air Consumption – 22 cfm
  • Air Pressure – 110 psi
  • Reverse – 8 turns
  • Blows/min – 470
VPT 250
  • Diameter – 2.6″
  • Length – 51.9″
  • Weight – 58 lb
  • Air Consumption – 31 cfm
  • Air Pressure – 110 psi
  • Reverse – 6 turns
  • Blows/min – 385
VPT 250 RT
  • Diameter – 2.6″
  • Length – 51.9″
  • Weight – 57 lb
  • Air Consumption – 31 cfm
  • Air Pressure – 110 psi
  • Reverse – 6 turns
  • Blows/min – 385
VPT 250 Short
  • Diameter – 2.6″
  • Length – 37″
  • Weight – 41 lb
  • Air Consumption – 31 cfm
  • Air Pressure – 110 psi
  • Reverse – 5 turns
  • Blows/min – 720
VPT 300
  • Diameter – 3″
  • Length – 56.1″
  • Weight – 76 lb
  • Air Consumption – 32 cfm
  • Air Pressure – 110 psi
  • Reverse – 5 turns
  • Blows/min – 480
VPT 300 RT
  • Diameter – 3″
  • Length – 56.1″
  • Weight – 74 lb
  • Air Consumption – 32 cfm
  • Air Pressure – 110 psi
  • Reverse – 5 turns
  • Blows/min – 480
VPT 400
  • Diameter – 3.9″
  • Length – 64″
  • Weight – 136 lb
  • Air Consumption – 68 cfm
  • Air Pressure – 110 psi
  • Reverse – 6 turns
  • Blows/min – 370
VPT 500
  • Diameter – 5.125″
  • Length – 68.5″
  • Weight – 214 lb
  • Air Consumption – 98 cfm
  • Air Pressure – 110 psi
  • Reverse – 7 turns
  • Blows/min – 333
